Side LED Destination Board
SPECIFICATION NO. : | AS:446:75:MAY:2010 |
DISPLAY SIZE | 900mm x 220mm x 60mm |
CHARACTER HEIGHT | 200mm |
DOT PITCH | 13.4mm (horizontal) x 14.1mm (vertical) |
FONTS: | ENGLISH & VARANACULAR |
VISIBILITY: | Clearly visible in Day and Night, in all weathers at a distance of 50 meters in the front |
BRIGHTNESS CONTROL | AUTOMATIC brightness control with light sensor |
DATA & DISPLAY CONTROL | 150 routes |
50 stops per route | |
300 destinations | |
VISUAL PATTERNS | STILL Messages |
Scrolling messages | |
Partial screen STILL and rest of the display scrolling | |
CPU PCB board | High speed MICROCONTROLLER |
DATA MEMORY 4 MB (for storing route information) | |
PRODCUT CONSTRUCTION | INDUSTRIAL/AUTOMOBILE GRADE, with bare minimum wire harness. |
Additional features | Works independently without control unit and voice announcement system. Routes can be downloaded through independent portable Controller. UP/DOWN/ROUTE selector switches |
INTER COMMUNICATION between LED BOARDS & CONTROLLER | RS232 |
RS485 | |
CAN (optional) | |
LIN (optional) | |
BLUETOOTH (optional) | |
CABINET | MS |
POWDER COATED | |
DUST Protected | |
Vibration protected | |
Rugged mounting brackets | |
INPUT VOLTAGE | 11 to 40V DC |
TEMPERATURE | 0o to 50o C |
HUMIDITY | 5% to 95% RH , NON Condensing |
